Titanium Exhaust Tube for Custom Motorcycle Mid-Pipes
Summary The titanium exhaust tube offers lightweight, corrosion-resistant performance for custom motorcycle exhausts. Its excellent weldability and stable dimensions make mid-pipes, connector tubes, and brackets easy to fabricate. Natural silver finish with optional polishing supports standard or custom-length builds.
Quick Specs Material: Industrial Pure Titanium (ASTM Grade 2, equivalent to Chinese TA10) Outer Diameter: 6 mm / 10 mm Wall Thickness: 1.0 mm Length: 500 mm standard (custom cutting available) Manufacturing Type: Seamless Tube Surface Finish: Silver / Polished Application: Motorcycle Exhaust Fabrication & Lightweight Mounting Brackets MOQ: 10 pcs
The titanium exhaust tube reduces overall exhaust mass, improving throttle response and handling agility. Riders experience clearer performance gains during acceleration and rapid directional changes.
● High Corrosion and Heat Resistance
Made from industrial-grade titanium (equivalent to ASTM Grade 2), the titanium exhaust tube tolerates continuous heat, moisture and road salt while retaining long-term durability. It maintains stable performance with fewer replacements over time.
● Easy to Work and Weld for Custom Builds
Its consistent material quality supports smooth TIG welding, precise cutting and controlled bending. This helps builders complete custom exhaust work faster while minimizing rework and material loss.
● Reliable Wall Strength with Tight Tolerances
A 1.0 mm wall and controlled dimensional accuracy reduce misalignment during fabrication, improving fit consistency. Builders gain more predictable results when joining sections or aligning exhaust joints.
● Polished Appearance with Custom Processing
The natural silver finish of titanium exhaust tube presents a clean, premium look that integrates well with modern motorcycle designs. It can also be polished or heat-colored for custom visual effects without compromising structural reliability.
Installation & Maintenance Guidance
● Welding
Prepare the tube ends and weld with TIG under full argon coverage. This protects against oxidation and ensures the titanium exhaust tube stays strong under heat and vibration.
● Bending & Cutting
Cut with smooth, burr-free tools and bend gently. Moderate curves and neat edges help prevent cracking or deformation during assembly.
● Exhaust Alignment
Position all sections before welding and allow room for thermal expansion. Proper layout spreads stress evenly, keeping the assembled system stable over time.
Technical Specifications
1. Material & Mechanical Properties
Parameter
Details
Material Grade
Industrial Pure Titanium (ASTM Grade 2, equivalent to Chinese TA10)
Standards Compliance
ASTM B338 / B861 (Equivalent to TA10 / Grade 2)
Density
4.51 g/cm³
Tensile Strength
~345 MPa (typical)
Corrosion Resistance
Excellent; ideal for marine and humid environments
Service Temperature
Recommended for continuous use up to ~300°C
Weldability
Excellent (TIG preferred)
2. Dimensional & Thread Data
Parameter
Details
Outer Diameter
6 mm / 10 mm
Wall Thickness
1.0 mm
Length
500 mm (custom lengths available)
Manufacturing Method
Seamless Tube
Dimensional Tolerance
OD ±0.1–0.15 mm
Delivery Condition
Annealed
Custom Range
OD 6–60 mm; WT 0.5–3.0 mm; lengths per request
3. Surface & Custom Options
Parameter
Details
Surface Finish
Raw Silver / Polished
Weldability
TIG-optimized; supports clean fusion and forming
Fabrication Options
Cutting, bending, small-batch machining
Optional Decoration
Low-temperature anodic coloring for visual upgrades
Application Scenarios
● Motorcycle
Exhaust Mid-Pipes & Connector Tubes
The titanium exhaust tube supports mid-pipes and slip-on connectors, offering low weight and heat stability. Builders achieve consistent alignment and smooth welds with minimal adjustments.
Silencer Inlet/Outlet Tubing
At muffler inlets and outlets, this tube ensures a stable connection with correct fit. Its precise diameter and wall thickness make shaping smooth transitions simple and reliable.
Lightweight Brackets & Support Rods
The titanium exhaust tube is strong yet light, making it suitable for hanger brackets, support rods, and heat-shield mounts. It reduces stress on fasteners and keeps mounts secure during vibration.
Visible Custom Build Elements
Often exposed on custom motorcycles. The tube’s natural silver finish can be polished or colored by heat treatment, offering flexible styling while keeping structural integrity.
● Small Equipment / Light Industrial
Compact Piping & Light Structural Members
For small fluid lines, vacuum tubes, or light frames, the titanium exhaust tube provides corrosion resistance and easy welding. Stable dimensions help workshops assemble parts quickly and accurately.
