Grade 5 Titanium Hex Head Bolts for Motorcycle, Automotive & Industrial Use - China Suppliers & Factory
Key Features
High Torque Efficiency & Precise Assembly
Titanium hex head bolts hex geometry maximizes torque transfer with minimal deformation. CNC-machined Grade 5 titanium enables lightweight yet robust assembly of motorcycle swingarms, automotive engine mounts, and industrial joints. This reliable torque characteristic supports repeated assembly and cyclic maintenance.
Superior Load & Thermal Resistance
These titanium hex head bolts maintain structural integrity under heavy loads and −100°C to +450°C. Suitable for high-vibration engine mounts, robotic arms, and precision machinery, providing long-term reliability and fatigue resistance.
Thread Versatility & Maintenance Efficiency
Available in metric coarse and fine threads (M3–M16) with ±0.05 mm tolerance and Cold-rolled threads reduce galling. These bolts support repeated disassembly without compromising torque retention, suitable for automotive, motorcycle, and industrial maintenance.
Custom Finishes & Branding Options
Polished, anodized, or PVD-coated finishes are available, along with optional color customization, logo engraving, and OEM packaging. Perfect for projects requiring specialized finishes or brand identification.
Lightweight & Fatigue-Resistant
Grade 5 titanium offers low density (4.43 g/cm³) while maintaining ≥900 MPa tensile strength. Using titanium hex head bolts reduces unsprung weight, improving handling stability and overall performance in motorcycles, bicycles, and e-bikes.
Installation & Maintenance Guidance
- ✓ Apply high-quality anti-seize compound for titanium-to-titanium or titanium-to-aluminum connections to prevent galling.
- ✓ Follow recommended torque specifications for each titanium hex head bolt size.
- ✓ Hex head allows easy access in tight spaces with standard hand or power tools.
Technical Specifications
1. Material & Mechanical Properties
| Parameter | Details |
| Material | Grade 5 Titanium (Ti-6Al-4V) |
| Density | 4.43 g/cm³ (≈55% lighter than steel) |
| Tensile Strength | ≥ 900 MPa |
| Yield Strength | ≥ 830 MPa |
| Hardness | 34–36 HRC |
| Fatigue & Shear | Excellent under vibration and cyclic load |
| Corrosion Resistance | Outstanding in salt, moisture, and heat |
| Standards Compliance | ISO 4014 (partial thread) / DIN 933 (full thread) |
2. Dimensional & Thread Data
| Parameter | Details |
| Diameter Range | M3–M16 |
| Length Range | 8–120 mm (custom lengths available) |
| Thread Pitch | 0.5–2.0 mm |
| Thread Type | Metric Coarse / Fine |
| Drive Type | Hex Head |
| Tolerance | ±0.05 mm |
| Head Dimensions | ISO Standard – refer to table |
3. Finishing & Customization Options
| Parameter | Details |
| Surface Finish | Polished / Anodized / PVD Coating |
| Color Options | Silver / Gold / Blue / Purple / Black |
| Logo Engraving | Available |
| Packaging | Bulk cartons / Custom retail sets |
| OEM Customization | Supported |
Application Scenarios
Motorcycle Performance & Suspension
Secure swingarms, brake mounts, and engine brackets with titanium hex head bolts (M6–M12). Lightweight Ti-6Al-4V reduces unsprung weight, improving handling and stability of high-performance motorcycles.
Automotive & Custom Vehicle Engineering
M8–M16 bolts are used in chassis frames, engine mounts, and flanged connections. They maintain precise clamping under vibration and thermal stress while enabling efficient assembly in tight engine bays.
High-End Bicycles & E-Bikes
They are also commonly applied in stems, brake calipers, and crank interfaces. Fatigue-resistant threads and lightweight design ensure repeated assembly without loss of torque or alignment.
Robotics & Industrial Equipment
In addition, titanium hex head bolts (M3–M16) can also be installed in robotic arms, modular machinery, and structural assemblies. Combines high-strength, corrosion resistance, and durability, allowing efficient assembly and disassembly in compact industrial setups.
Frequently Asked Questions
Q: What is the material grade of these hex head bolts and what are its key properties?
These hex head bolts are made of Grade 5 Titanium (Ti-6Al-4V). Key properties include a low density of 4.43 g/cm³ (approximately 55% lighter than steel), high tensile strength of ≥ 900 MPa, yield strength of ≥ 830 MPa, hardness of 34–36 HRC, and outstanding corrosion resistance in salt, moisture, and heat.
Q: What temperature range can these titanium hex head bolts withstand?
These titanium hex head bolts maintain their structural integrity under heavy loads and extreme temperatures ranging from −100°C to +450°C, making them suitable for high-vibration and high-temperature engine mounts.
Q: How do I prevent galling during the installation of titanium bolts?
To prevent galling, it is highly recommended to apply a high-quality anti-seize compound whenever making titanium-to-titanium or titanium-to-aluminum connections. Also, ensure you follow the recommended torque specifications for each specific bolt size.
Q: What dimensional sizes, thread types, and tolerances do you offer?
We offer diameters ranging from M3 to M16 and lengths from 8 to 120 mm (with custom lengths available). The thread types include metric coarse and fine threads with a pitch range of 0.5–2.0 mm and a strict tolerance of ±0.05 mm. They comply with ISO 4014 and DIN 933 standards.
Q: What custom finishes and customization options are available?
We provide polished, anodized, or PVD-coated surface finishes. Color options include silver, gold, blue, purple, and black. We also support custom logo engraving, custom retail packaging, and full OEM customization.
Q: Where are these titanium hex head bolts typically applied?
They are widely used in motorcycle performance parts (swingarms, brake mounts, engine brackets), automotive and custom vehicle engineering (chassis frames, engine mounts), high-end bicycles and e-bikes (stems, brake calipers, crank interfaces), and robotics or industrial machinery.
